Hitachi L300P Series Quick Reference Guide

26
“C” Group: Intelligent Terminal Functions
B108 Free-setting V/f frequency (5) 0.
B109 Free-setting V/f voltage (5) 0.0
B110 Free-setting V/f frequency (6) 0.
B111 Free-setting V/f voltage (6) 0.0
B112 Free-setting V/f frequency (7) 0.
B113 Free-setting V/f voltage (7) 0.0
Func.
Code
Name / Description
Default
Valu e
–FE2/–FU2/
–FR
Set
Valu e
C001 Terminal [1] function 33 option codes
available (34 codes
for
–xFE2/–xFU2
models)
(see page 31)
18
C002 Terminal [2] function 16
C003 Terminal [3] function 03 / 13 / 03
C004 Terminal [4] function 02
C005 Terminal [5] function 01
C011 Terminal [1] active state • 00 Normally open
[NO]
• 01 Normally
closed [NC]
00
C012 Terminal [2] active state 00
C013 Terminal [3] active state 00 / 01 / 00
C014 Terminal [4] active state 00
C015 Terminal [5] active state 00
C019 Terminal [FW] active
state
00
C021 Terminal [11] function 12 option codes
available (13 codes
for
–xFE2/–xFU2
models)
(see page 32)
01
C022 Terminal [12] function 00
C026 Alarm relay terminal
function
05
Func.
Code
Name / Description
Default
Valu e
–FE2/–FU2/
–FR
Set
Valu e
