Intelligent Input Terminal Listing
Symbol Code Input Terminal Name
RV 01 Reverse Run/Stop
CF1 02 Multi-speed select, Bit 0 (LSB)
CF2 03 Multi-speed select, Bit 1
CF3 04 Multi-speed select, Bit 2
CF4 05 Multi-speed select, Bit 3 (LSB)
JG 06 Jogging
DB 07 External DC injection braking signal
SET 08 Set (select) second motor data
2CH 09 2-stage accel and decel
FRS 11 Free-run stop
EXT 12 External trip
USP 13 Unattended start protection
CS 14 Commercial power source
SFT 15 Software lock
AT 16 Analog input voltage/current sel.
RS 18 Reset inverter
STA 20 Start (3-wire interface)
STP 21 Stop (3-wire interface)
F/R 22 FW, RV (3-wire interface)
PID 23 PID ON/OFF
PIDC 24 PID Reset
UP 27 Remote control Up func.
DWN 28 Remote control Down func.
UDC 29 Remote control data clearing
OPE 31 Operator control
SF1–SF7 32–38 Multi-speed bits 1 to 7
OLR 39 Overload restriction
ROK 49 Run Enable for FW/RV
(–xFU2 and –xFE2 models only)
