Hitachi L300P Series Quick Reference Guide

32
Intelligent Output Terminal Listing
Symbol Code Input Terminal Name
RUN 00 Run signal
FA1 01 Freq. arrival type 1 – constant speed
FA2 02 Freq. arrival type 2 – over-frequency
OL 03 Overload advance notice signal
OD 04 Output deviation for PID control
AL 05 Alarm signal
FA3 06 Freq. arrival type 3 – at frequency
IP 08 Instantaneous power failure signal
UV 09 Under-voltage signal
RNT 11 Run time over
ONT 12 Power-ON time over
THM 13 Thermal alarm signal
RMD 27 Run command source monitor
(–xFU2 and –xFE2 models only)

Hitachi L300P Series Specifications

General

Brand	Hitachi
Model	L300P Series
Category	Inverter
Language	English
