Hitachi L300P Series Service Manual

1- 7
Function mode
Code Function name SJ300 Setting range
Initial data
-FE/-FU/-F
Note
b034
RUN time/Power ON time level
0.-9999./1000-6553(10000-65530)hr 0.
b035 Operation direction restrict 00(Reverse is valid)/01(Only forward)/02(Only reverse) 00
b036 Start reduced voltage 00(Start reduced voltage time small)-06(Start reduced voltage time large) 06
b037
Display selection 00(all display)/01(each function display)/02(User setting / main setting) 00
b040 Torque limit mode selection
00(4 quadrant mode)/01(Terminal operation)/
02(Analog input)/03(Option1)/04(Option2)
00
b041
Torque limit level 1 setting
(Forward-driving at
4 quadrant mode)
0.-200.(%)/no(Invalid) <0.-180.(%)/no(Invalid)> 150.
b042
Torque limit level 2 setting
(Reverse-regenerating at
4 quadrant mode)
0.-200.(%)/no(Invalid) <0.-180.(%)/no(Invalid)> 150.
b043
Torque limit level 3 setting
(Reverse-driving at
4 quadrant mode)
0.-200.(%)/no(Invalid) <0.-180.(%)/no(Invalid)> 150.
b044
Torque limit level 4 setting
(Forward-regenerating at
4 quadrant mode)
0.-200.(%)/no(Invalid) <0.-180.(%)/no(Invalid)> 150.
b045
Torque LAD-STOP selection
00(Invalid)/01(Valid) 00
b046
Reverse run prevention
selection
00(Invalid)/01(Valid) 00
b050
Selection of non-stop
function at instantaneous
power failure
00(Invalid)/01(Valid) 00
b051
Start voltage of non-stop
function setting
0.0-1000.(V) 0.0
b052
OV LAD-STOP level of non-
stop function setting
0.0-1000.(V) 0.0
b053
Deceleration time of non-
stop function setting
0.01-99.99/100.0-999.9/1000.-3600.(s) 1.00
b054
Deceleration frequency width
of non-stop function setting
0.00-10.00(Hz) 0.00
b080
AM adjustment 0. - 255. 180
b081
FM adjustment 0. - 255. 60
b082 Start frequency adjustment 0.10-9.99(Hz) 0.50
b083
Carrier frequency setting 0.5-15.0(kHz) Derating enable, <0-10kHz>
5.0 <3.0>
b084 Initialize mode
00(Trip history clear)/01(Data initialization)/
02(Trip history clear + data initialization)
00
b085
Country code for initialization
00(Interior)/01(EC)/02(USA)
01/02/00
b086
Frequency scalar conversion
factor
0.1-99.9 1.0
b087
STOP key enable 00(valid)/01(invalid) 00
b088
Resume on FRS cancellation
mode
00(0Hz start)/01(Start f-equaling) 00
b090
BRD usage ratio 0.0-100.0(%) 0.0
b091
Stop mode selection 00(deceleration stop)/01(Free-run stop) 00
b092 Cooling fan control
00(Always ON)/
01(ON during run, After power ON, then for 5 minutes on stop is implied.)
00
b095
BRD selection 00(invalid)/01(valid<invalid during stop>)/02(valid<valid during stop>) 00
b096
BRD ON level 330-380/660-760(V) 360/720
b098
Thermistor selection 00(invalid)/01(Positive temperature coefficient enable)/02 (NTC enable) 00
b099 Thermistor error level 0. - 9999. (ohm) 3000.
b120 Braking control selection 00(Invalid)/01(valid) 00
b121
Waiting time for releasing
braking conformation
0.00-5.00(s) 0.00
b122
Waiting time for acceleration
0.00-5.00(s) 0.00
b123
Waiting time for stop 0.00-5.00(s) 0.00
b124
Waiting time for signal
conformation
0.00-5.00(s) 0.00
b125
Releasing frequency 0.00-99.99/100.0-400.0(Hz) 0.00
b126 Releasing current 0.00*rated current-2.00*rated current(A)
Rated
current of
inverter
C091
Debug mode selection 00(No display)/01(Display) 00
C101
UP/DWN selection 00(No frequency data)/01(Keep frequency data) 00
C102 Reset selection
00(Trip cancel during ON)/01(Trip cancel during OFF)/
02(Valid only during trip<Cancel during ON>)
00
C103
Reset f frequency matching
selection
00(0Hz start)/01(Start f-equaling) 00
C111
Overload advance notice
level
0.0-2.0*rated current(A)
Inverter
rated
current
C121 O zero adjustment 0.-9999./1000-6553(10000-65530)
Set on
forwarding
C122 OI zero adjustment 0.-9999./1000-6553(10000-65530)
Set on
forwarding
C123 O2 zero adjustment 0.-9999./1000-6553(10000-65530)
Set on
forwarding
(Note) < > indicate the setting range of 75 to 150kW
The others
