Hitachi L300P Series Service Manual

1- 8
Function mode
Code Function name SJ300 Setting range
Initial data
-FE/-FU/-F
Note
H001 Autotuning selection
00(Invalid)/01(Valid(the motor does not rotate))/
02( Valid(the motor rotates))
00
H002 1
st
motor constant selection
00(Hitachi general purpose motor data)/01(Autotuning data)/
02( Autotuning data with online autotuning)
00
H202 2
nd
motor constant selection
00(Hitachi general purpose motor data)/01(Autotuning data)/
02( Autotuning data with online autotuning)
00
H003 1
st
allowable motor selection 0.20-75.0(kW) <0.2-160(kW)>
Set on
forwarding
H203 2
nd
allowable motor selection 0.20-75.0(kW) <0.2-160(kW)>
Set on
forwarding
H004
1
st
motor pole selection 2/4/6/8(pole) 4
H204
2
nd
motor pole selection 2/4/6/8(pole) 4
H005
1
st
speed response setting 0.001-9.999/10.00-65.53 1.590
H205
2
nd
speed response setting 0.001-9.999/10.00-65.53 1.590
H006
1
st
stabilized factor 0. - 255. 100.
H206 2
nd
stabilized factor 0. - 255. 100.
H306 3
rd
stabilized factor 0. - 255. 100.
H020 1
st
motor constant R1 0.000-9.999/10.00-65.53(ohm)
Set on
forwarding
H220 2
nd
motor constant R1 0.000-9.999/10.00-65.53(ohm)
Set on
forwarding
H021 1
st
motor constant R2 0.000-9.999/10.00-65.53(ohm)
Set on
forwarding
H221 2
nd
motor constant R2 0.000-9.999/10.00-65.53(ohm)
Set on
forwarding
H022 1
st
motor constant L 0.00-99.99/100.0-655.3( mH)
Set on
forwarding
H222 2
nd
motor constant L 0.00-99.99/100.0-655.3( mH)
Set on
forwarding
H023 1
st
motor constant I0 0.00-99.99/100.0-655.3(A)
Set on
forwarding
H223 2
nd
motor constant I0 0.00-99.99/100.0-655.3(A)
Set on
forwarding
H024 1
st
motor constant J
0.001-9.999/10.00-99.99/100.0-9999.( kgm
2
)
Set on
forwarding
H224 2
nd
motor constant J
0.001-9.999/10.00-99.99/100.0-9999.( kgm
2
)
Set on
forwarding
H030
1
st
motor constant R1
(Autotuning data)
0.000-9.999/10.00-65.53(ohm)
Set on
forwarding
H230
2
nd
motor constant R1
(Autotuning data)
0.000-9.999/10.00-65.53(ohm)
Set on
forwarding
H031
1
st
motor constant R2
(Autotuning data)
0.000-9.999/10.00-65.53(ohm)
Set on
forwarding
H231
2
nd
motor constant R2
(Autotuning data)
0.000-9.999/10.00-65.53(ohm)
Set on
forwarding
H032
1
st
motor constant L
(Autotuning data)
0.00-99.99/100.0-655.3( mH)
Set on
forwarding
H232
2
nd
motor constant L
(Autotuning data)
0.00-99.99/100.0-655.3( mH)
Set on
forwarding
H033
1
st
motor constant I0
(Autotuning data)
0.00-99.99/100.0-655.3(A)
Set on
forwarding
H233
2
nd
motor constant I0
(Autotuning data)
0.00-99.99/100.0-655.3(A)
Set on
forwarding
H034 1
st
motor constant J 0.001-9.999/10.00-99.99/100.0-9999.( kgm
2
)
Set on
forwarding
H234 2
nd
motor constant J 0.001-9.999/10.00-99.99/100.0-9999.( kgm
2
)
Set on
forwarding
H050
1
st
PI-control proportion gain
setting
0.00-99.99/100.0-999.9/1000.(%) 100.0
H250
2
nd
PI-control proportion gain
setting
0.00-99.99/100.0-999.9/1000.(%) 100.0
H051
1
st
PI-control integration gain
setting
0.00-99.99/100.0-999.9/1000.(%) 100.0
H251
2
nd
PI-control integration gain
setting
0.00-99.99/100.0-999.9/1000.(%) 100.0
H052
1
st
P-control proportion gain
setting
0.01-10.00 1.00
H252
2
nd
P-control proportion gain
setting
0.01-10.00 1.00
H060
1
st
0Hz-SLV limiter setting 0.-100.(%) 100.
H260
2
nd
0Hz-SLV limiter setting 0.-100.(%) 100.
H070
PI-control proportion gain for
switching
0.00-99.99/100.0-999.9/1000.(%) 100.0
H071
PI-control integration gain for
switching
0.00-99.99/100.0-999.9/1000.(%) 100.0
H072
P-control proportion gain for
switching
0.00-10.00 1.00
(Note) < > indicate the setting range of 75 to 150kW
The others
