Hitachi L300P Series Service Manual

1- 9
Function mode
Code Function name SJ300 Setting range
Initial data
-FE/-FU/-F
Note
P001
Option1 operation selection
on error
00(TRP)/01(RUN) 00
P002
Option2 operation selection
on error
00(TRP)/01(RUN) 00
P010
Feed-back option selection 00(Invalid)/01(Valid) 00
P011
Encoder pulse number
setting
128.-9999./1000-6500(10000-65000) (pulse) 1024
P012
Control mode selection 00(ASR mode)/01(APR mode) 00
P013
Pulse train input mode
selection
00(Mode 0)/01(Mode 1)/02(Mode 2)/03(Mode 3) 00
P014
Orientation stop position
setting
0.-4095. 0.
P015
Orientation speed setting 0.00-99.99/100.0-120.0(Hz) 5.00
P016
Orientation direction
selection
00(Forward)/01(Reverse) 00
P017
Orientation completion range
setting
0.-9999./1000(10000) (pulse) 5
P018
Orientation completion delay
time setting
0.00-9.99(s) 0.00
P019
Electronic gear position
selection
00(Feedback)/01(Reference) 00
P020
Electronic gear numerator of
ratio setting
0.-9999. 1.
P021
Electronic gear denominator
of ratio setting
0.-9999. 1.
P022
Position control feed-forward
gain setting
0.00-99.99/100.0-655.3 0.00
P023
Position control loop gain
setting
0.00-99.99/100.0 0.50
P025
Compensation of secondary
resistor selection
00(Invalid)/01(Valid) 00
P026
Over-speed detect level
setting
0.00-99.99/100.0-150.0(%) 135.0
P027
Speed-error over detect level
setting
0.00-99.99/100.0-120.0(Hz) 7.50
P031
Digital input option input
mode selection (Acc/Dec)
00(operator)/01(option1)/02(option2) 00
P032
Stop position setting for
orientation input mode
selection
00(operator)/01(option1)/02(option2) 00
P044
DeviceNet running order of
monitoring timer setting
0.00-99.99s 1.00
P045
Setting in action of abnormal
communication
00(trip)/01(trip after deceleration stop)/02(invalid)/
03(free-run)04(deceleration stop)
0.
P046
Output assemble instance
Number setting
20,21,100 21
P047
Input assemble instance
Number setting
70,71,101 71
P048
Detect of idol mode for
motion setting
00(trip)/01(trip after deceleration stop)/02(invalid)/
03(free-run)04(deceleration stop)
01
P049 Pole setting of rotation speed 0-38(even only) 0
U001 User1 selection no/d001-P049 <-P032> no
U002 User2 selection no/d001-P049 <-P032> no
U003
User3 selection no/d001-P049 <-P032> no
U004
User4 selection no/d001-P049 <-P032> no
U005
User5 selection no/d001-P049 <-P032> no
U006
User6 selection no/d001-P049 <-P032> no
U007
User7 selection no/d001-P049 <-P032> no
U008
User8 selection no/d001-P049 <-P032> no
U009
User9 selection no/d001-P049 <-P032> no
U010 User10 selection no/d001-P049 <-P032> no
U011
User11 selection no/d001-P049 <-P032> no
U012
User12 selection no/d001-P049 <-P032> no
(Note 1) P044-P049 are displayed on a 0.4-55kW model.
User selection
Option
