Hitachi L300P Series Service Manual

1- 3
Function Mode
Code Function name SJ300 Setting range
Initial data
-FE/-FU/-F
Note
A001 Frequency setting selection 01(terminal)/02(operator)/03(RS485)/04(option1)/05(option2) 01/01/02
A002 Operation setting selection 01(terminal)/02(operator)/03(RS485)/04(option1)/05(option2) 01/01/02
A003 Base frequency 30. - Maximum. frequency(Hz) 50./60./60.
A203 Base frequency, 2nd motor 30. – 2nd Maximum. frequency (Hz) 50./60./60.
A303 Base frequency, 3rd motor 30. - 3rd Maximum. frequency (Hz) 50./60./60.
A004 Maximum frequency 30. – 400. (Hz) 50./60./60.
A204 Maximum frequency, 2nd motor 30. – 400. (Hz) 50./60./60.
A304 Maximum frequency, 3rd motor 30. – 400. (Hz) 50./60./60.
A005 AT terminal selection
00( Changing of O and OI with AT terminal)/
01(Changing of O and O2 with AT terminal)
00
A006 02 selection
00(single)/01(auxiliary speed of O, OI) [no reversible] /
02(auxiliary speed of O, OI [reversible]
00
A011 0 start 0.00-99.99/100.0-400.0 (Hz) 0.00
A012 0 end 0.00-99.99/100.0-400.0 (Hz) 0.00
A013 0 start rate 0.-100.0 (%) 0.
A014 0 end rate 0.-100.0(%) 100.
A015 0 start selection 00 (external starting frequency)/01(0Hz) 01
A016 O, OI, O2 sampling 1.-30.(times) 8.
A019 Multi-speed selection
00(binary : range is to 16 stage speed with 4 terminals)/
01(bit : range is to 8 stage speed with 7 terminals)
00
A020 Multi-speed 0 0.00, starting frequency-maximum. frequency(Hz) 0.00
A220 Multi-speed 0, 2
nd
motor 0.00, starting frequency-2
nd
maximum frequency(Hz) 0.00
A320 Multi-speed 0, 3
rd
motor 0.00, starting frequency-3
rd
maximum frequency(Hz) 0.00
A021 Multi-speed1 0.00, starting frequency-maximum frequency(Hz) 0.00
A022 Multi-speed2 0.00, starting frequency-maximum frequency(Hz) 0.00
A023 Multi-speed3 0.00, starting frequency-maximum frequency(Hz) 0.00
A024 Multi-speed4 0.00, starting frequency-maximum frequency(Hz) 0.00
A025 Multi-speed5 0.00, starting frequency-maximum frequency(Hz) 0.00
A026 Multi-speed6 0.00, starting frequency-maximum frequency(Hz) 0.00
A027 Multi-speed7 0.00, starting frequency-maximum frequency(Hz) 0.00
A028 Multi-speed8 0.00, starting frequency-maximum frequency(Hz) 0.00
A029 Multi-speed9 0.00, starting frequency-maximum frequency(Hz) 0.00
A030 Multi-speed10 0.00, starting frequency-maximum frequency(Hz) 0.00
A031 Multi-speed11 0.00, starting frequency-maximum frequency(Hz) 0.00
A032 Multi-speed12 0.00, starting frequency-maximum frequency(Hz) 0.00
A033 Multi-speed13 0.00, starting frequency-maximum frequency(Hz) 0.00
A034 Multi-speed14 0.00, starting frequency-maximum frequency(Hz) 0.00
A035 Multi-speed15 0.00, starting frequency-maximum frequency(Hz) 0.00
A038 Jogging frequency 0.00, starting frequency-9.99(Hz) 1.00
A039 Jogging selection
00(free-run on JG stop / invalid on running) / 01(stop decelerating on
JG stop / invalid on running) / 02(DC braking on JG stop/invalid on
running) / 03(free-run on JG stop/valid on running[JG after stop
decelerating]) / 04 (stop decelerating on JG stop/valid on running) / 05
(DC braking on JG stop/valid on operating)
00
A041 Torque boost selection 00 (manual torque boost) / 01 (automatic torque boost) 00
A241
Torque boost selection, 2
nd
motor
00 (manual torque boost) / 01 (automatic torque boost) 00
A042 Manual torque boost 0.0-20.0(%) 1.0
A242 Manual torque boost, 2
nd
motor 0.0-20.0(%) 1.0
A342 Manual torque boost, 3
rd
motor 0.0-20.0(%) 1.0
A043 Manual torque boost point 0.0-50.0(%) 5.0
A243
Manual torque boost point, 2
nd
motor
0.0-50.0(%) 5.0
A343
Manual torque boost point, 3
rd
motor
0.0-50.0(%) 5.0
A044 1
st
control
00/(VC)/01(VP1.7power)/02(free V/f setting)/03(SLV)/
04(0Hz-SLV)/05(V2)
00
A244 2
nd
control 00/(VC)/01(VP1.7power)/02(free V/f setting) /03(SLV)/04(0Hz-SLV) 00
A344 3
rd
control 00/(VC)/01(VP1.7power) 00
A045 Output voltage gain 20. - 100. 100.
A051 DC braking selection 00(invalid)/01(valid) 00
A052 DC braking frequency 0.00-60.00(Hz) 0.50
A053 DC braking wait time 0.0 - 5.0(s) 0.0
A054 DC braking power 0. - 100. (%) <0.-80.(%)> 0.
A055 DC braking time 0.0 - 60.0(s) 0.0
A056 DC braking edge/level selection 00(edge action)/01(level action) 01
A057 DC braking power (starting time) 0. - 100. (%) <0.-80.(%)> 0.
A058 DC braking time(starting time) 0.00-60.0(s) 0.0
A059 DC carrier frequency 0.5-15(kHz) Derating <0.5-10kHz> 5.0<3.0>
(Note) < > indicate the setting range of 75 to 150kW
Base setting
Analog input setting
Multistage speed,jogging frequency setting
V/f characteristic
Direct current braking
