Hitachi L300P Series Service Manual

1- 4
Function Mode
Code Function name SJ300 Setting range
Initial data
-FE/-FU/-F
Note
A061
1
st
frequency maximum limiter 0.00, 1
st
frequency lower limitter - maximum frequency(Hz) 0.00
A261
2
nd
frequency maximum limiter
0.00, 2
nd
frequency lower limiter-2
nd
setting maximum frequency(Hz)
0.00
A062
1
st
frequency minimum limiter 0.00, start frequency-maximum frequency(Hz) 0.00
A262
2
nd
frequency minimum limiter 0.00, start frequency-2
nd
setting maximum frequency(Hz) 0.00
A063 Jump frequency1 0.00-99.99/100.0-400.0(Hz) 0.00
A064
Jump frequency Width 1 0.00-10.00(Hz) 0.50
A065
Jump frequency2 0.00-99.99/100.0-400.0(Hz) 0.00
A066
Jump frequency Width 2 0.00-10.00(Hz) 0.50
A067
Jump frequency3 0.00-99.99/100.0-400.0(Hz) 0.00
A068
Jump frequency Width 3 0.00-10.00(Hz) 0.50
A069
Acceleration stop frequency 0.00-99.99/100.0-400.0(Hz) 0.00
A070 Acceleration stop time 0.00-60.0(s) 0.0
A071 PID selection 00(invalid)/01(valid) 00
A072
PID-P gain 0.2-5.0 1.0
A073
PID-I gain 0.0-3600.(s) 1.0
A074
PID-D gain 0.00-100.0(s) 0.00
A075
PID scale 0.01-99.99(%) 1.00
A076
PID feedback selection 00(feedback : OI)/01(feedback : O) 00
A081
AVR selection 00(ON always)/01(OFF always)/02(OFF on decelerating) 00/00/02
A082 Motor voltage selection 200/215/220/230/240, 380/400/415/440/460/480
(230/400)/
(230/460)/
(200/400)
A085
Operation mode selection 00(normal operation)/01(energy-saving operation)/02(Fuzzy) 00
A086
Energy-saving response-
accuracy adjustment
0.0-100.0 50.0
A092
Acceleration time2 0.01-99.99/100.0-999.9/1000.-3600.(s) 15.00
A292 Acceleration time2(2
nd
motor) 0.01-99.99/100.0-999.9/1000.-3600.(s) 15.00
A392 Acceleration time2(3
rd
motor) 0.01-99.99/100.0-999.9/1000.-3600.(s) 15.00
A093
Deceleration time2 0.01-99.99/100.0-999.9/1000.-3600.(s) 15.00
A293
Deceleration time2(2
nd
motor) 0.01-99.99/100.0-999.9/1000.-3600.(s) 15.00
A393
Deceleration time2(3
rd
motor) 0.01-99.99/100.0-999.9/1000.-3600.(s) 15.00
A094
2
nd
stage adjustable selection 00(change with 2CH terminal)/01(change with setting) 00
A294
2
nd
stage adjustable
selection(2
nd
motor)
00(change with 2CH terminal)/01(change with setting) 00
A095
2
nd
acceleration frequency 0.00-99.99/100.0-400.0(Hz) 0.00
A295
2
nd
acceleration
frequency(2
nd
motor)
0.00-99.99/100.0-400.0(Hz) 0.00
A096
2
nd
deceleration frequency 0.00-99.99/100.0-400.0(Hz) 0.00
A296
2
nd
deceleration frequency
(2
nd
motor)
0.00-99.99/100.0-400.0(Hz) 0.00
A097
Acceleration pattern selection 00(straight line)/01(S-curve)/02(U-curve)/03(reverse U-curve) 00
A098 Deceleration pattern selection 00(straight line)/01(S-curve)/02(U-curve)/03(reverse U-curve) 00
A101 OI start 0.00-99.99/100.0-400.0(Hz) 0.00
A102
OI end 0.00-99.99/100.0-400.0(Hz) 0.00
A103
OI start rate 0.-100. (%) 20.
A104
OI end rate 0.-100. (%) 100.
A105
OI start selection 00(external start frequency)/01(0Hz) 01
A111
O2 start -400.--100./-99.9-0.00-99.9/100.-400.(Hz) 0.00
A112
O2 end -400.--100./-99.9-0.00-99.9/100.-400.(Hz) 0.00
A113 O2 start rate -100. - 100. (%) -100.
A114
O2 end rate -100. - 100. (%) 100.
A131
Acceleration curve constant 01(small swelling)-10(large swelling) 02
A132 Deceleration curve constant 01(small swelling-10(large swelling) 02
b001 Retry selection
00(trip)/01(0Hz start)/02(start after equal frequency)/
03(trip after equaling frequency and deceleration stop)
00
b002
Allowable under-voltage power
failure time
0.3-1.0(s) 1.0
b003
Retry wait time 0.3-100.(s) 1.0
b004
Instantaneous power failure/
under-voltage trip during stop
00(invalid/01(valid)/02(invalid during stop and deceleration by stop
command)
00
b005
Instantaneous power failure/
under-voltage retry time
selection
00(16 times)/01(free) 00
b006 Open-phase selection 00(invalid)/01(valid) 00
b007
Frequency setting to match 0.00-99.99/100.0-400.0(Hz) 0.00
Upper and lower
limiter,jump
frequency
PID controlAVR
Operation mode/ adjustable function
External frequency
adjustment
Accel,
Decel
Instantaneous power failure
restart
