Hitachi L300P Series Instruction Manual Supplement

L300P Supplement Explanation of functions
Function mode
Code Function name Setting range
LBRM/HFBM
Initial Data
LFU/HFU
Initial data
b012 Electronic thermal level 0.2*constant current-1.20*constant current(A)
Rated current
of inverter×
1.20
Rated
current
of inverter
b212
Electronic thermal level
(2
nd
motor)
0.2*constant current-1.20*constant current(A)
Rated current
of inverter×
1.20
Rated
current
of inverter
b013
Electronic thermal
characteristic selection
00/(reduced characteristic)/01(constant characteristic)/
02(free setting)
00 01
b213
Electronic thermal
characteristic selection
(2
nd
motor)
00/(reduced characteristic)/01(constant torque characteristic)/
02(free setting)
01 01
b015
Free electronic
thermal frequency1
0.-400.(Hz) 0. 0.
b016
Free electronic thermal
current1
0.0-1000.(A) 0.0 0.0
b017
Free electronic thermal
frequency2
0.-400.(Hz) 0. 0.
b018
Free electronic thermal
current2
0.0-1000. (A) 0.0 0.0
b019
Free electronic thermal
frequency3
0.-400.(Hz) 0. 0.
Electronic thermal
b020
Free electronic thermal
current3
0.0-1000.(A) 0.0 0.0
b021
Overload restriction
selection
00(invalid)/01(enabled on acceleration･constant speed)/
02(enabled on constant speed)
01 01
b022 Overload restriction level 0.50* rated current-1.50* rated current(A)
Rated Current
of inverter
×1.20
Rated
Current
of inverter
×1.20
b023
Overload restriction
limit constant
0.10-30.00(s) 10.00 1.00
b024
Overload restriction
2 selection
00(invalid)/01(valid on acceleration･constant speed)/
02(valid on constant speed)
01 01
b025 Overload restriction level2 0.50*rated current-1.50*rated current(A)
Rated current
of inverter×
1.20
Rated
current
of inverter
×1.20
b026
Overload restriction
constant2
0.10-30.00(s) 1.00 1.00
Overload restriction
b031
Software lock mode
selection
00(impossible to change the data except this item on SFT terminal
ON)/
01(impossible to change the data except setting frequency item on SFT
terminal is ON)/02(impossible to change the data except this item)/
03(impossible to change the data except setting frequency item)/
10(possible to change data on operating)
01 01
b100 Free V/f frequency1 0.- Free V/f frequency2(Hz) 0. 0.
b101 Free V/f voltage1 0.-800.0(V) 0.0 0.0
b102 Free V/f frequency2 0.- Free V/f frequency3(Hz) 0. 0.
b103 Free V/f voltage 2 0.-800.0(V) 0.0 0.0
b104 Free V/f frequency3 0.- Free V/f frequency4(Hz) 0. 0.
b105 Free V/f voltage 3 0.-800.0(V) 0.0 0.0
b106 Free V/f frequency4 0.- Free V/f frequency5(Hz) 0. 0.
b107 Free V/f voltage 4 0.-800.0(V) 0.0 0.0
b108 Free V/f frequency5 0.- Free V/f frequency6(Hz) 0. 0.
b109 Free V/f voltage 5 0.-800.0(V) 0.0 0.0
b110 Free V/f frequency6 0.- Free V/f frequency7(Hz) 0. 0.
b111 Free V/f voltage 6 0.-800.0(V) 0.0 0.0
b112 Free V/f frequency7 0.-400.(Hz) 0. 0.
Free V/f setting
b113 Free V/f voltage 7 0.-800.0(V) 0.0 0.0
