L300P Supplement Explanation of functions
Function Mode
C001 Intelligent input1 setting 18 18
C002 Intelligent input2 setting 16 16
C003 Intelligent input3 setting 49 13
C004 Intelligent input4 setting 02 02
Intelligent input terminal setting
C005 Intelligent input5 setting
01/(RV:Reverse Run/Stop)/02(CF1:Multi-speed1)/03(CF2:Multi-speed2)/
04(CF3:Multi-speed3)/05(CF4:Multi-speed4)/06(JG:Jogging)/
07(DB:External DC braking)/08(SET:2
nd
control)/
09(2CH:two-stage adjustable speed)/
11(FRS:Free-run)/12(EXT:External trip)/
13(USP:Unattended start protection)/14(CS:commercial change)/
15(SFT:software lock)/16(AT:Analog input voltage/current select)/
18(RS:Reset inverter)/20(STA:3wire run)/21(STP:3wire keep)/
22(F/R:3wire forward/reverse)/23(PID:PID selection valid/invalid) /
24(PIDC:PID integrating reset)/
27(UP:Remote control UP function)/28(DWN:Remote control DOWN function)/
29(UDC:Remote control data clear)/32(SF1:Multi-speed bit1)/
33(SF2:Multi-speed bit2)/34(SF3:Multi-speed bit3)/35(SF4:Multi-speed bit4)/
36(SF5:Multi speed bit5)/37(SF6:Multi-speed bit6)/38(SF7:Multi-speed bit7)/
39(OLR:Overload restriction change)/no(NO:No assign)
49(ROK: permissive input signal for FW/REV) NOTE (2)
01 01
Code Function name Setting range
LBRM/HFBM
Initial Data
LFU/HFU
Initial data
NOTE (2) : See Page 1(ROK: RUN Permissive input signal for FW/REV)
9
To Next Page
