Hitachi L300P Series Instruction Manual Supplement

L300P Supplement Explanation of functions
Function mode
Code Function name Setting range
LBRM/HFBM
Initial Data
LFU/HFU
Initial data
C011
Intelligent input1a/b(NO/NC)
selection
00(NO)/01(NC) 00 00
C012
Intelligent input2a/b(NO/NC)
selection
00(NO)/01(NC) 00 00
C013
Intelligent input3a/b(NO/NC)
selection
00(NO)/01(NC) 00 01
C014
Intelligent input4a/b(NO/NC)
selection
00(NO)/01(NC) 00 00
C015
Intelligent input5a/b(NO/NC)
selection
00(NO)/01(NC) 00 00
Input terminal setting
intelligent
C019
Input FWa/b(NO/NC)
selection
00(NO)/01(NC) 00 00
C021 Intelligent output 11 setting 27 01
C022 Intelligent output 12 setting 00 00
C026 Alarm relay output setting
00(RUN:running)/01(FA1:Frequency arrivaltype1 signal)/
02(FA2:frequency arrival type2 signal)/
03(OL:Overload advance notice signal)/
04(OD:Output deviation for PID control)/
05(AL:Alarm signal)/06(FA3:Only setting frequency)/
08(IP:On instantaneous stop/09(UV:Under voltage/
11(RNT:RUN time over/
12(ONT:ON time over)/13(THM:thermal caution)/
27(RMD: RUN command source) NOTE (3)
05 05
C027 FM selection
00(Output frequency)/01(Output current) /
03(Digital output frequency)/04(Output voltage)/
05(Output electric power)/06(thermal load rate)/07(LAD
frequency)
00 00
C028 AM selection
00(Output frequency)/01(Output current)/04(Output voltage)/
05(Output electric power)/06(thermal load rate)/07(LAD
frequency)
00 00
O
utput terminal state setting･Output level setting
C029 AMI selection
00(Output frequency)/01(Output current)/04(Output voltage)/
05(Output electric power)/06(Thermal load rate)/07(LAD
frequency)
00 00
C031 Intelligent output 11a/b 00(NO)/01(NC) 00 00
C032 Intelligent output 12a/b 00(NO)/01(NC) 00 00
C036 Alarm relay output a/b 00(NO)/01(NC) 00 01
C040
Overload advance notice
signal output mode
00(On accel. And decel, constant speed)/
01(Only constant speed)
01 01
C041 Overload notice level 0.0-2.0*rated current(A)
Inverter rated
current
Inverter
rated
current
C042
Frequency arrival setting for
accel.
0.00-99.99/100.0-400.0(Hz) 0.00 0.00
C043
Arrival frequency setting for
decel.
0.00-99.99/100.0-400.0(Hz) 0.00 0.00
C044 PID deviation setting level 0.0-100.0(%) 3.0 3.0
Communication function adjustment
C061
Electorical thermal protection
warning level setting
0.-100.(%) 80. 80.
C070 Data command 02(operator)/03(RS485)/04(option1)/05(option2) 02 02
C071
Communicating transmission
speed
02(TEST)/03(2400bps)/04(4800bps)/05(9600bps)/06(19200bps) 04 04
C072 Communication code 1. -32. 1. 1.
C073 Communication bit 7(7bit)/8(8bit) 7 7
C074 Communication parity 00(no parity name)/01(even parity)/02(odd parity) 00 00
C075 Communication stop bit 1(bit)/2(bit) 1 1
Analog meter setting
C078 Communication waiting time 0.-1000.(ms) 0. 0.
C081 O adjustment 0.-9999./1000-6553(10000-65530)
Setting on
forwarding
Setting on
forwarding
C082 OI adjustment 0.-9999./1000-6553(10000-65530)
Setting on
forwarding
Setting on
forwarding
C083 O2 adjustment 0.-9999./1000-6553(10000-65530)
Setting on
forwarding
Setting on
forwarding
C085 Thermistor adjustment 0.0 - 1000. 105.0 105.0
C086 AM offset adjustment 0.0 - 10.0(V) 0.0 0.0
C087 AMI adjustment 0. - 255. 80 80
C088 AMI offset adjustment 0. - 20.0(mA) 4.0 4.0
NOTE (3) : See Page 1 (RMD : Output signal for RUN Command Source)
