9
2. GENERAL DESCRIPTION [Components]
Cooling fan
Intercooler
Aftercooler
Oil cooler
Air intake filter
Oil mist remover
(OMR)
Control panel
Enclosure
Instrument panel
Main motor
Discharge pipe
(Compressed air discharge)
Check valve
Common Base
Air relief valve
Oil filter
1st-stage
Airend
2nd-stage
Airend
Oil level gauge
[Front View]
[Rear View]
Water-Cooled
DSP-45/55/75WTN
DSP-55/75VWTN
