8
2. GENERAL DESCRIPTION [Components]
2.2 Components
Oil cooler
Intercooler
Aftercooler
Air intake filter
Oil mist remover
(OMR)
Discharge pipe
(Compressed air discharge)
Oil level gauge
Control panel
Enclosure
Instrument panel
Main motor
Oil filter
1st-stage
Airend
2nd-stage
Airend
Check valve
Cooling fan
Common base
Air relief valve
[Front View]
[Rear View]
Air-Cooled
DSP-45/55/75ATN
DSP-55/75VATN
