Hitachi NEXT Series User Manual

4
1. SAFETY PRECAUTIONS
WARNING
Rotating Parts!
WARNING
Electric Shock Hazard!
WARNING
Electric Shock Hazard!
WARNING
Hot Surface!
Heated!!
Air End
Discharge Air
pipe
WARNING
Hot Surface!
Do not directly touch any component
inside the air compressor enclosure
when the air compressor is operating
or immediately after it has stopped,
as the components are extremely hot
and can cause severe injury.
Before servicing the air compressor,
stop it, disconnect the power, then wait
for the air compressor to cool down.
Discharge Air
Pipe
Air End
Heated!!
WARNING
Hot Surface!
Aftercooler
header
Intercooler
header
Heated!!
● Fixed speed type
● Vtype
Do not directly touch any component
inside the air compressor enclosure
when the air compressor is operating
or immediately after it has stopped,
as the components are extremely hot
and can cause severe injury.
Before servicing the air compressor,
stop it, disconnect the power, then
wait for the air compressor to cool
down.
●
●
Do not directly touch any component
inside the air compressor enclosure
when the air compressor is operating
or immediately after it has stopped,
as the components are extremely hot
and can cause severe injury.
Before servicing the air compressor,
stop it, disconnect the power, then
wait for the air compressor to cool
down.
●
●
●
●
Before servicing or wiring the air compressor,
disconnect the power. This will prevent anyone from
turning on the power and causing an electric shock
that could lead to severe injury or death.
Do not allow any unlicensed person to wire the air
compressor. Always use a licensed electrician.
Ground the air compressor.
●
●
●
●
●
●
10 minutes before servicing or wiring the air
compressor, disconnect the power. This will prevent
anyone from turning on the power and causing an
electric shock that could lead to severe injury or death.
Do not allow any unlicensed person to wire the air
compressor. Always use a licensed electrician.
Ground the air compressor.
Keep hands and rods, etc. away from the rotating parts
(Cooling fans, etc.)
Use caution at all times, when air compressor is
powered. The air compressor may be capable of
restarting without hitting the START button.
When the air compressor is operating, do not remove or
open the enclosure panels and doors.
Before servicing the air compressor, stop it, disconnect the
power, especially when accessing any rotating parts.
●
●
●
●
Water-Cooled
DSP-45/55/75WTN
DSP-55/75VWTN

Hitachi NEXT Series Specifications

General

Brand	Hitachi
Model	NEXT Series
Category	Air Compressor
Language	English
