81
Item
Part Name
Q'TY
No.
1 TOP COVER 1
2 HEX. SOCKET HD. BOLT M5 × 20 4
3 EXHAUST COVER 1
4 HEAD VALVE O-RING 1
5 HEAD VALVE SPRING 1
6 HEAD VALVE (A) 1
7 GASKET 1
8 O-RING (P22.4) 1
9 PISTON 1
10 O-RING (I.D 44.7) 1
11 CYLINDER PLATE 1
12 O-RING (S-30) 1
13 O-RING (P32) 1
14 CYLINDER 1
15 PISTON BUMPER 1
16 BUMPER PIECES 1
17 NAMEPLATE 1
18 WARNING LABEL 1
19 RETAINING RING (E-TYPE) FOR D6 SHAFT 1
20 BODY ASS'Y 1
21 GRIP RUBBER (A) 1
22 GASKET (B) 1
23 CAP (A) 1
24 HEX. SOCKET HD. BOLT M5 × 16 5
25 AIR PLUG NPT 1/4 1
26 STEEL BALL D3.97 1
27 SPRING (C) 1
28 CHANGE KNOB (C) 1
29 HITACHI LABEL 1
30 PROTECTOR 1
31 TRIGGER (C) ASS'Y 1
32 PUSHING LEVER GUIDE 1
33 PUSHING SPRING (A) 1
35 PUSHING LEVER (C) 1
36 ADJUSTER 1
37 PUSHING LEVER (B) 1
38 PUSHING LEVER (A) 1
39 RETAINING RING (E-TYPE) FOR D3 SHAFT 1
40 NOSE CAP 1
41 TRIGGER ARM (C) 1
42 ROLL PIN D2.5 × 16 1
43 ROLL PIN D3 × 25 1
44 ROLL PIN D3 × 25 1
45 ROLL PIN D3 × 32 1
46 VALVE BUSHING (A) 1
47 FEED PISTON O-RING (I.D.14) 1
48 VALVE BUSHING (B) 1
49 O-RING (P-18) 1
50 O-RING (P-7) 2
51 VALVE PISTON 1
52 O-RING (1AP-10) 1
53 PLUNGER SPRING 1
54 O-RING (I.D 1.8) 2
55 PLUNGER 1
56 LOCK LEVER 1
Item
Part Name
Q'TY
No.
57 ROLL PIN D3 × 18 2
58 GUIDE PLATE 1
59 HEX. SOCKET HD. BOLT M4 × 10 1
60 BLADE GUIDE 1
61 LABEL 1
62 MAGAZINE A'SSY 1
64 NYLON NUT M4 1
65 ROLL PIN D3 × 20 1
66 STOPPER LEVER 1
67 SPRING 1
68 PLATE 1
69 HEX. SOCKET HD. BOLT M4 × 10 1
70 HEX. SOCKET HD. BOLT M4 × 25 1
71 NAIL FEEDER 1
72 NAIL PLATE 1
73 FEEDER PIECE 1
74 FEED SPRING 1
75 MAGAZINE COVER 1
76 LABEL (A) 1
501 SAFETY GLASSES 1
502 CASE 1
NT50AE2
