Magazine
WARNING
WARNING
Nail Stopper
ADJUSTING AIR PRESSURE
● Do not exceed 120 psi
(8.3 bar 8.5 kgf/cm
2
).
Adjust the air pressure at recommended operating pressure 70 – 120 psi (4.9 – 8.3 bar 5 –
8.5 kgf/cm
2
) according to the length of nails and the hardness of workpiece.
The correct air pressure is the lowest pressure which will do the job. Using the Nailer at a
higher than required air pressure unnecessarily over stresses the Nailer.
LOADING NAILS
● When loading nails into the nailer, be sure to remove your finger
from the trigger and disconnect the air hose from the nailer.
(1) Insert nail strip into rear of magazine.
(2) Slide the nail strip forward in the magazine.
The nail strip should pass the nail stopper.
To Next Page
