Hitachi NT 65MA2 - Specifications; Nail Selection

English
9
SPECIFICATIONS
Operating pressure
Dimensions
Length × Height × Width
Weight
Nail capacity
Air consumption
Air inlet
70 – 120 psi (4.9 – 8.3 bar 5 – 8.5 kgf/cm
2
)
13 - 17/32" × 11 - 31/32" × 3 - 7/32"
(344 mm × 304 mm × 82 mm)
4.4 lbs. (2.0 kg)
100 Nails
.042 ft
3
/cycle at 100 psi
(1.20 ltr/cycle at 6.9 bar)
(1.20 ltr/cycle at 7 kgf/cm
2
)
3/8 NPT Thread
NAIL SELECTION
WARNING
● Be sure to use only the genuine HITACHI nails for the
NT65MA2. The use of any other nails can result in tool mal-
function and/or nail breakdown, leading to serious injuries.
Only nails shown in the Table below can be driven with this Nailer.
Dimensions of nails
Max.
.095" (2.4mm)
1-1/4" (32mm)
.045"
(1.1mm)
.072" (1.8mm)
2-1/2" (65mm)
15 Gauge finish nails Min.
.12"
(3.0mm)
