English
— 10 —
SPECIFICATIONS
NAIL SELECTION
WARNING
䢇 Be sure to use only the genuine HITACHI nails for the NV45AB2/NV45AB2(S). The
use of any other nails can result in tool malfunction and/or nail breakdown, leading
to serious injuries.
Only nails shown in the Table below can be driven with this Nailer.
ACCESSORIES
WARNING
䢇 Accessories other than those shown below can lead to malfunction and resulting
injuries.
Wire-collated coil nails Min. Max.
.413"
(10.5 mm)
.120"
(3.05 mm)
7/8" (22 mm)
.413"
(10.5 mm)
.120"
(3.05 mm)
1-3/4" (45 mm)
Model NV45AB2 NV45AB2(S)
Operating pressure 70 – 120 psi (4.9 – 8.3 bar 5 – 8.5 kgf/cm
2
)
Dimensions
9-27/32" × 10-3/8" × 4-5/8" 9-27/32" × 10-3/8" × 4-7/8"
Length × Height × Width
(250 mm × 264 mm × 117 mm) (250 mm × 264 mm × 124 mm)
Weight 5.5 lbs (2.5 kg)
Magazine type Top loading Bottom loading
Nail capacity 120 nails (1 coil)
.046 ft
3
/cycle at 100 psi
Air consumption (1.3 ltr/cycle at 6.9 bar)
(1.3 ltr/cycle at 7 kgf/cm
2
)
Air inlet 3/8 NPT Thread
01Eng_NV45AB2_US 2/26/09, 11:4510
