Hitachi P42A01 Service Manual

B1-5
DISASSEMBLY INSTRUCTIONS
Remove the 22 screws 1.
Remove the Shield Main.
Remove the PDP Filter.
1-5: PDP FILTER
1.
2.
3.
Shield Main Top
Shield Main L
Shield Main R
Shield Main Bottom
PDP Filter
