10.2 ELECTRICAL WIRING CONNECTION FOR OUTDOOR UNITS
L2
N
2
10.2.1 Setting of DIP switches for outdoor unit
Quantity and Position of DIP Switches
DSW1: No setting is required
DSW301: Test run mode
DSW2: Optional Function setting (Setting is
required)
DSW3: Capacity Setting (No setting is required)
Model RAS-2WHVRP
Model RAS-2.5WHVRP
Model RAS-3WHVRP
DSW4 / RSW1: No setting is required (do not
change)
DSW5: End terminal resistance (No setting is
required)
DSW6: No setting is required (do not change)
PMML0509 rev.0 - 02/2019
