Hitachi Relion 650 Series User Manual

Table 100: Truth table for the Set-Reset (SRMEMORY) function block
SET RESET OUT NOUT
1 0 1 0
0 1 0 1
1 1 1 0
0 0 Last
value
Inverted
last value
Function block
D0E6803T201305151403 v1
SRMEMORY
SET
RESET
OUT
NOUT
IEC09000293-1-en.vsd
D0E13114T201305151403 V1 EN-US
Figure 59: SRMEMORY function block
Signals
D0E7304T201305151403 v1
Table 101: SRMEMORY Input signals
Name Type Default Description
SET BOOLEAN 0 Input signal to set
RESET BOOLEAN 0 Input signal to reset
D0E7305T201305151403 v1
Table 102: SRMEMORY Output signals
Name
Type Description
OUT BOOLEAN Output signal
NOUT BOOLEAN Inverted output signal
Settings
D0E7306T201305151403 v1
Table 103: SRMEMORY Group settings (basic)
Name
Values (Range) Unit Step Default Description
Memory Off
On
- - On Operating mode of the memory function
11.1.1.11 Reset-set with memory function block RSMEMORY
Identification
D0E6887T201305151403 v1
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Reset-set with memory function block RSMEMORY - -
Functionality
D0E6846T201305151403 v3
The Reset-set with memory function block (RSMEMORY) is a flip-flop with memory that can reset or
set an output from two inputs respectively. Each RSMEMORY function block has two outputs, where
one is inverted. The memory setting controls if the flip-flop after a power interruption will return to the
state it had before or if it will be reset. In RSMEMORY, the RESET input has priority over SET input.
1MRK 511 557-UEN Rev. A Section 11
Logic
123
Technical Manual
© 2021 Hitachi Energy. All rights reserved.
