Name Type Values (Range) Unit Description
OvTrigStatCh38 BOOLEAN - - Over level trig for analog channel 38
activated
UnTrigStatCh39 BOOLEAN - - Under level trig for analog channel 39
activated
OvTrigStatCh39 BOOLEAN - - Over level trig for analog channel 39
activated
UnTrigStatCh40 BOOLEAN - - Under level trig for analog channel 40
activated
OvTrigStatCh40 BOOLEAN - - Over level trig for analog channel 40
activated
FaultNumber INTEGER - - Disturbance fault number
12.4.3 Analog input signals AxRADR
D0E7518T201305151403 v1
12.4.3.1 Identification
D0E7495T201305151403 v1
Function description IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Analog input signals A1RADR - -
Analog input signals A2RADR - -
Analog input signals A3RADR - -
12.4.3.2 Function block
D0E7479T201305151403 v1
A1RADR
^GRPINPUT1
^GRPINPUT2
^GRPINPUT3
^GRPINPUT4
^GRPINPUT5
^GRPINPUT6
^GRPINPUT7
^GRPINPUT8
^GRPINPUT9
^GRPINPUT10
IEC09000348-1-en.vsd
D0E13250T201305151403 V1 EN-US
Figure 98: A1RADR function block, analog inputs, example for A1RADR, A2RADR and
A3RADR
12.4.3.3 Signals
A1RADR - A3RADR Input signals
D0E7498T201305151403 v1
Tables for input signals for A1RADR, A2RADR and A3RADR are similar except for GRPINPUT
number.
• A1RADR, GRPINPUT1 - GRPINPUT10
• A2RADR, GRPINPUT11 - GRPINPUT20
• A3RADR, GRPINPUT21 - GRPINPUT30
Section 12 1MRK 511 557-UEN Rev. A
Monitoring
188
Technical Manual
© 2021 Hitachi Energy. All rights reserved.
