11.5.4 Signals
D0E5613T201305151403 v1
Table 143: IB16A Input signals
Name Type Default Description
BLOCK BOOLEAN 0 Block of function
INP INTEGER 0 Integer Input
D0E5614T201305151403 v1
Table 144: IB16A Output signals
Name Type Description
OUT1 BOOLEAN Output 1
OUT2 BOOLEAN Output 2
OUT3 BOOLEAN Output 3
OUT4 BOOLEAN Output 4
OUT5 BOOLEAN Output 5
OUT6 BOOLEAN Output 6
OUT7 BOOLEAN Output 7
OUT8 BOOLEAN Output 8
OUT9 BOOLEAN Output 9
OUT10 BOOLEAN Output 10
OUT11 BOOLEAN Output 11
OUT12 BOOLEAN Output 12
OUT13 BOOLEAN Output 13
OUT14 BOOLEAN Output 14
OUT15 BOOLEAN Output 15
OUT16 BOOLEAN Output 16
11.5.5 Settings
D0E4794T201305151403 v1
The function does not have any parameters available in local HMI or Protection and Control IED
Manager (PCM600)
11.5.6 Operation principle
D0E5074T201305151403 v3
Integer to boolean 16 conversion function (IB16A) is used to transform an integer (0...65535) into a
set of 16 binary (logical) signals, with the least significant bit mapped to OUT1. IB16A function is
designed for receiving the integer input locally. Activating the BLOCK input will freeze the logical
outputs at the last value.
1MRK 511 557-UEN Rev. A Section 11
Logic
141
Technical Manual
© 2021 Hitachi Energy. All rights reserved.
