Description Type test value Reference
0.5...30 MHz <73 dB(µV) quasi peak
<60 dB(µV) average
• Radiated RF-emission, IEC
30...230 MHz <40 dB(µV/m) quasi peak, measured
at 10 m distance
230...1000 MHz <47 dB(µV/m) quasi peak, measured
at 10 m distance
17.13 Insulation tests
D0E7975T201305151403 v1
Table 438: Insulation tests
Description Type test value Reference
Dielectric tests: IEC 60255-5
ANSI C37.90-2005
• Test voltage 2 kV, 50 Hz, 1 min
1 kV, 50 Hz, 1 min, communication
Impulse voltage test: IEC 60255-5
ANSI C37.90-2005
• Test voltage 5 kV, unipolar impulses, waveform
1.2/50 μs, source energy 0.5 J
1 kV, unipolar impulses, waveform
1.2/50 μs, source energy 0.5 J,
communication
Insulation resistance measurements IEC 60255-5
ANSI C37.90-2005
• Isolation resistance >100 MΏ, 500 V DC
Protective bonding resistance IEC 60255-27
• Resistance <0.1 Ώ (60 s)
17.14 Mechanical tests
D0E8295T201305151403 v1
Table 439: Mechanical tests
Description
Reference Requirement
Vibration response tests (sinusoidal) IEC 60255-21-1 Class 1
Vibration endurance test IEC 60255-21-1 Class 1
Shock response test IEC 60255-21-2 Class 1
Shock withstand test IEC 60255-21-2 Class 1
Bump test IEC 60255-21-2 Class 1
Seismic test IEC 60255-21-3 Class 2
17.15 Product safety
D0E7923T201305151403 v1
Section 17 1MRK 511 557-UEN Rev. A
Technical data
438
