Section 9 Control
9.1 Selector mini switch VSGGIO
9.1.1 Identification
D0E7201T201305151403 v1
Function description IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Selector mini switch VSGGIO - -
9.1.2 Functionality
D0E7200T201305151403 v3
The Selector mini switch VSGGIO can be used for a variety of applications, as a general purpose
switch. It can be used for two purposes:
• Acquiring an external switch position at its inputs. This information can be represented on the
single line diagram by a controllable switch symbol, or used further in the application.
• Issuing switching commands on its outputs. Here, VSGGIO can be controlled from the menu or
from a symbol on the single line diagram (SLD) on the local HMI.
9.1.3 Function block
D0E7330T201305151403 v1
VSGGIO
BLOCK
PSTO
IPOS1
IPOS2
BLOCKED
POSITION
POS1
POS2
CMDPOS12
CMDPOS21
IEC09000341-1-en.vsd
D0E13222T201305151403 V1 EN-US
9.1.4 Signals
D0E7324T201305151403 v1
Table 25: VSGGIO Input signals
Name
Type Default Description
BLOCK BOOLEAN 0 Block of function
PSTO INTEGER 0 Operator place selection
IPOS1 BOOLEAN 0 Position 1 indicating input
IPOS2 BOOLEAN 0 Position 2 indicating input
D0E7325T201305151403 v1
Table 26: VSGGIO Output signals
Name
Type Description
BLOCKED BOOLEAN The function is active but the functionality is blocked
POSITION INTEGER Position indication, integer
POS1 BOOLEAN Position 1 indication, logical signal
Table continues on next page
1MRK 511 557-UEN Rev. A Section 9
Control
67
Technical Manual
© 2021 Hitachi Energy. All rights reserved.
