3-6 ●Basic operation
* Thoroughly wipe off the makeup on the surface of each part (including the mounting base) and dry each part
thoroughly with wiping paper.
Clean the inside of the cleaning section with makeup.
Clean the orifice plate, charge electrode, deflection electrode, gutter, and mounting base with makeup.
(Also see “1.3 Print head cleaning”.)
3
Loosen the screw and remove the print head cover.
2
Orifice plate
Charge electrode
Deflection electrode
Mounting base
Beaker
Cleaning bottle
Gutter
Area to be cleaned
Loosen the screw.
Print head cover
Pull out.
Around nozzle
To Next Page
