S1 series standard inverter
-152-
Detailed parameter description
Display input frequency of HDIB
Range: 0.000–50.000kHz
Note: up to 2.2kW, P17.22=HDI input frequency
Display PID reference value
Range: -100.0–100.0%
Display PID feedback value
Range: -100.0–100.0%
Display the power factor of current motor.
Range: -1.00–1.00
Display current running time of the inverter.
Range: 0–65535min
Current step
number of
multi-step speed
Current step number of multi-step speed
Range: 0–15
Motor ASR
controller output
Display the speed loop ASR controller output
value under vector control mode, relative to the
percentage of rated torque of the motor.
Range: -300.0%–300.0% (rated motor current)
Exciting current
reference
Display the exciting current reference value under
vector control mode
Range: -3000.0–3000.0A
Display torque current reference value under
vector control mode
Range: -3000.0–3000.0A
Display the valid value of incoming current on AC
side
Range: 0.0–5000.0A
Display output torque value, during forward
running, positive value is motoring state, negative
value is generating state; during reverse running,
positive value is generating state, negative value
is motoring state.
Range: -3000.0Nm–3000.0Nm
Motor overload
count value
