Hitachi S1 Series User Manual

S1 series standard inverter
-186-
MSB of data writing address
00H
LSB of data writing address
04H
MSB of to-be-written data
13H
LSB of to-be-written data
88H
LSB of CRC
C5H
MSB of CRC
6EH
END
T1-T2-T3-T4 (transmission time of 3.5 bytes)
RTU slave response (transmitted by the inverter to the master)
START
T1-T2-T3-T4 (transmission time of 3.5 bytes)
ADDR
02H
CMD
06H
MSB of data writing address
00H
LSB of data writing address
04H
MSB of to-be-written data
13H
LSB of to-be-written data
88H
LSB of CRC
C5H
MSB of CRC
6EH
END
T1-T2-T3-T4 (transmission time of 3.5 bytes)
9.4.3 Command code: 08H, diagnosis
Sub-function code description
Sub-function code
Description
0000
Return data based on query requests
For example, to query about the circuit detection information about the inverter whose address is 01H,
the query and return strings are the same, and the format is described in the following tables.
RTU master command
START
T1-T2-T3-T4 (transmission time of 3.5 bytes)
ADDR
01H
CMD
08H
MSB of the sub-function code
00H
LSB of the sub-function code
00H
MSB of data
12H
LSB of data
ABH
LSB of CRC CHK
ADH
MSB of CRC CHK
14H
END
T1-T2-T3-T4 (transmission time of 3.5 bytes)

Hitachi S1 Series Specifications

General

Output Frequency	0 - 400 Hz
Overload Capacity	150% for 60 seconds
Frequency	50/60 Hz
Control Method	Sensorless Vector Control
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit
Communication	RS485, Modbus RTU
Output Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC (Matches Input Voltage)
Cooling Method	Fan Cooled
