Hitachi S1 Series User Manual

S1 series standard inverter
-189-
Function
Address
Data description
R/W
0006H: Coast to stop (emergency stop)
0007H: Fault reset
0008H: Jogging to stop
Communication-based
value setting
2001H
Communication-based frequency setting (0–
Fmax, unit: 0.01 Hz)
R/W
2002H
PID setting, range (0–1000, 1000 corresponding
to 100.0%)
2003H
PID feedback, range (0–1000, 1000
corresponding to 100.0%)
R/W
2004H
Torque setting (-3000–+3000, 1000
corresponding to 100.0% of the rated current of
the motor)
R/W
2005H
Setting of the upper limit of the forward running
frequency (0–Fmax, unit: 0.01 Hz)
R/W
2006H
Setting of the upper limit of the reverse running
frequency (0–Fmax, unit: 0.01 Hz)
R/W
2007H
Upper limit of the electromotion torque (0–3000,
1000 corresponding to 100.0% of the rated
current of the inverter)
R/W
2008H
Upper limit of the brake torque (0–3000, 1000
corresponding to 100.0% of the rated current of
the motor)
R/W
2009H
Special control command word:
Bit1–0 =00: Motor 1 =01: Motor 2
=10: Motor 3 =11: Motor 4
Bit2: =1 Torque control disabled =0: Torque
control cannot be disabled
Bit3: =1 Power consumption reset to 0
=0: Power consumption not reset
Bit4: =1 Pre-excitation =0: Pre-excitation
disabled
Bit5: =1 DC brake =0: DC brake disabled
R/W
200AH
Virtual input terminal command, range: 0x000–
0x1FF
R/W
200BH
Virtual output terminal command, range: 0x00–
0x0F
R/W
200CH
Voltage setting (used when V/F separation is
implemented)
(0–1000, 1000 corresponding to 100.0% of the
R/W

Hitachi S1 Series Specifications

General

Output Frequency	0 - 400 Hz
Overload Capacity	150% for 60 seconds
Frequency	50/60 Hz
Control Method	Sensorless Vector Control
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit
Communication	RS485, Modbus RTU
Output Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC (Matches Input Voltage)
Cooling Method	Fan Cooled
