S1 series standard inverter
-190-
Function
Address
Data description
R/W
rated voltage of the motor)
200DH
AO output setting 1 (-1000+1000, 1000
corresponding to 100.0%)
R/W
200EH
AO output setting 2 (-1000+1000, 1000
corresponding to 100.0%)
R/W
Inverter state word 1
2100H
0001H: Forward running
R
0002H: Reverse running
0003H: Stopped
0004H: Faulty
0005H: POFF
0006H: Pre-excited
Inverter state word 2
2101H
Bit0: =0: Not ready to run =1: Ready to run
Bit21: =00: Motor 1 =01: Motor 2
=10: Motor 3 =11: Motor 4
Bit3: =0: Asynchronous machine
Bit4: =0: No overload alarm =1: Overload alarm
Bit65: =00: Keypad-based control =01:
Terminal-based control
=10: Communication-based control
Bit7: Reserved
Bit8: =0: Speed control =1: Torque control
Bit9: =0: Non-position control =1: Position
control
Bit1110: =0: Vector 0 =1: Vector 1 =2:
Closed-loop vector =3: Space voltage vector
R
Inverter fault code
2102H
See the description of fault types.
R
Running frequency
3000H
0Fmax (unit: 0.01Hz)
R
Set frequency
3001H
0Fmax (unit: 0.01Hz)
R
Bus voltage
3002H
0.02000.0 V (unit: 0.1V)
R
Output voltage
3003H
01200V (unit: 1V)
R
Output current
3004H
0.03000.0A (unit: 0.1A)
R
Rotating speed
3005H
065535 (unit: 1RPM)
R
Ouptut power
3006H
-300.0+300.0% (unit: 0.1%)
R
Output torque
3007H
-250.0+250.0% (unit: 0.1%)
R
Closed-loop setting
3008H
-100.0+100.0% (unit: 0.1%)
R
Closed-loop feedback
3009H
-100.0+100.0% (unit: 0.1%)
R
Input state
300AH
0001FF
R
Output state
300BH
0001FF
R
Analog input 1
300CH
0.0010.00V (unit: 0.01V)
R
