S10 Series SIO Driver
GP-Pro EX Device/PLC Connection Manual
22
Option
To display the setting screen, touch [Device/PLC Settings] from [Peripheral Equipment Settings]. Touch the
External Device you want to set from the displayed list, and touch [Option].
Setup Items Setup Description
RI/VCC
You can switch RI/VCC of the 9th pin when you select RS232C for SIO type.
When you connect to IPC, you need to use the IPC change switch to change RI/5V. Please
refer to the manual of IPC for details.
• GP-4100 series, GP-4*01TM and GP-Rear Module do not have the [Option] setting in the
offline mode.
To Next Page
