2
18.5 25 –185LFU 1 3.6 4.9
22 30 –220LFU 1/0 AWG 6.5 8.8
30 40 –300LFU 1/0 || 1/0 AWG 6.5 8.8
37 50 –370LFU 1/0 || 1/0 AWG 6.5 8.8
45 60 –450LFU 1/0 || 1/0 AWG 10.1 13.7
55 75 –550LFU 2/0 || 2/0 AWG 10.1 13.7
400V Models
Motor output
Inverter
Model
Wire Size (AWG)
Torque
kW HP ft-lbs (N-m)
0.75 1 –007HFU/E 20 1.1 1.5
1.5 2 –015HFU/E 18 1.1 1.5
2.2 3 –022HFU/E 16 1.1 1.5
4.0 5 –037HFU/E 14 1.1 1.5
5.5 7 1/2 –055HFU/E 12 1.8 2.5
7.5 10 –075HFU/E 10 1.8 2.5
11 15 –110HFU/E 8 3.6 4.9
15 20 –150HFU/E 6 3.6 4.9
18.5 25 –185HFU/E 6 3.6 4.9
22 30 –220HFU/E 4 3.6 4.9
30 40 –300HFU/E 3 3.6 4.9
37 50 –370HFU/E 1 3.6 4.9
45 60 –450HFU/E 1AWG (75°C) 6.5 8.8
55 75 –550HFU/E 1/0 || 1/0 AWG 6.5 8.8
75 100 –750HFU/E
3/0 (1/0 || 1/0
AWG)
6.5 8.8
90 125 –900HFU/E 10.1 13.7
110 150 –1100HFU/E 1/0 || 1/0 AWG 10.1 13.7
200V Models
Motor output
Inverter
Model
Wire Size (AWG)
Torque
kW HP ft-lbs (N-m)
