Analog Input Configuration
The following tables show the parameter settings required for various
analog input signal types.
The table below applies when the [AT] input function is not assigned to
any intelligent input terminal. The A005 setting, normally used in con-
junction with an [AT] input, is ignored.
A006 A005 [AT]
External
Frequency
Command
Input
Trim
Frequency
Command
Input
Reverse
available
(bipolar
input)
00 00 OFF [O] — [L] ✘✘
ON [OI] — [L] ✘✘
01 OFF [O] — [L] ✘✘
ON [O2] — [L] ✘✔
01 00 OFF [O] — [L] [O2] — [L] ✘
ON [OI] — [L] [O2] — [L] ✘
01 OFF [O] — [L] [O2] — [L] ✘
ON [O2] — [L] ✘✔
02 00 OFF [O] — [L] [O2] — [L] ✔
ON [OI] — [L] [O2] — [L] ✔
01 OFF [O] — [L] [O2] — [L] ✔
ON [O2] — [L] ✘✔
A006 A005 [AT]
External
Frequency
Command
Input
Trim
Frequency
Command
Input
Reverse
available
(bipolar
input)
00 — (not
assigned
to any
input
termi-
nal)
[O2] — [L] ✘✔
01 — Summation of
[O] — [L] and
[OI] — [L]
[O2] — [L] ✘
02 — Summation of
[O] — [L] and
[OI] — [L]
[O2] — [L] ✔
