Hitachi SJ300 Series

36
Intelligent Output Terminal Listing
PPI 43 P / PI mode selection
BOK 44 Brake confirmation signal
ORT 45 Orientation (home search)
LAC 46 LAC: LAD cancel
PCLR 47 Position deviation reset
STAT 48 Pulse train position cmd enable
Symbol Code Input Terminal Name
RUN 00 Run signal
FA1 01 Freq. arrival type 1 – constant speed
FA2 02 Freq. arrival type 2 – over-frequency
OL 03 Overload advance notice signal
OD 04 Output deviation for PID control
AL 05 Alarm signal
FA3 06 Freq. arrival type 3 – at frequency
OTQ 07 Over-torque signal
IP 08 Instantaneous power failure signal
UV 09 Under-voltage signal
TRQ 10 In torque limit signal
RNT 11 Run time over
ONT 12 Power-ON time over
THM 13 Thermal alarm signal
BRK 19 Brake release signal
BER 20 Brake error signal
ZS 21 Zero speed detect
DSE 22 Speed deviation maximum
POK 23 Positioning completion
FA4 24 Freq. arrival type 4 – over-frequency (2)
FA5 25 Freq. arrival type 5 – at frequency (2)
OL2 26 Overload advance notice signal (2)
Symbol Code Input Terminal Name
