Intelligent Input Terminal Listing
Symbol Code Input Terminal Name
RV 01 Reverse Run/Stop
CF1 02 Multi-speed select, Bit 0 (LSB)
CF2 03 Multi-speed select, Bit 1
CF3 04 Multi-speed select, Bit 2
CF4 05 Multi-speed select, Bit 3 (LSB)
JG 06 Jogging
DB 07 External DC injection braking signal
SET 08 Set (select) second motor data
2CH 09 2-stage accel and decel
FRS 11 Free-run stop
EXT 12 External trip
USP 13 Unattended start protection
CS 14 Commercial power source
SFT 15 Software lock
AT 16 Analog input voltage/current sel.
SET3 17 Set (select) 3rd motor data
RS 18 Reset inverter
STA 20 Start (3-wire interface)
STP 21 Stop (3-wire interface)
F/R 22 FW, RV (3-wire interface)
PID 23 PID ON/OFF
PIDC 24 PID Reset
CAS 26 Control gain setting
UP 27 Remote control Up func.
DWN 28 Remote control Down func.
UDC 29 Remote control data clearing
OPE 31 Operator control
SF1–SF7 32–38 Multi-speed bits 1 to 7
OLR 39 Overload restriction
TL 40 Torque limit enable
TRQ1 41 Torque limit select, bit 1 (LSB)
TRQ2 42 Torque limit select, bit 2 (MSB)
