Note: Set frequency (speed) values are not permitted to be inside
the jump frequency ranges, if defined. When a frequency ref-
erence value from a real-time source (such as keypad potenti-
ometer or analog input) are inside a jump frequency range, the actual
speed is automatically forced to equal the lowest point of the jump range.
Auto-tuning Procedure
The SJ300 auto-tuning feature calibrates the inverter to the parameters of
a specific motor such as winding resistance and reactance. For optimum
sensorless vector control, it is important to auto-tune during the initial
installation, and after replacing either the motor or the inverter.
Auto-tuning requires that you configure the inverter for the desired type
of vector control (set A044 = 03, 04, or 05). Then you can perform the
auto-tuning procedure, which is detailed in the SJ300 Inverter Instruction
Manual.
110
B100, B102, B104,
B106, B108, B110
>B112
B102, B104, B106,
B108, B110
<B100
B100 > B102
B104, B106, B108,
B110
<
B100, B102 > B104
B106, B108, B110 <
B100, B102, B104 > B106
B108, B110 <
B100, B102, B104,
B106
>B108
B110 <
B100, B102, B104,
B106, B108
>B110
120
B017, B019 < B015
B015 > B017
B019 <
B015, B017 > B019
Prg Error Code
Function code of
parameter out of
bounds
Boundary defined by...
<, > Base parameter
