Hitachi UTOPIA R32 Series Technical Catalogue

3 General data
Component data
TCGB0136 rev.1 - 05/2021
44

RAS-(4-6)H(V)(R/N)P2E
MODEL RAS-4H(V)(R/N)P2E RAS-5H(V)(R/N)P2E RAS-6H(V)(R/N)P2E
Heat
exchanger
Type Multi-passcross-nnedtube
Pipe material Copper
Outer diameter mm 7
Rows 2
Number of tubes in the heat
exchanger
108
Fin material Aluminium
Fin pitch 1.4
Maximum operating
pressure
MPa 4.15
Total front area m
2
1.11
Number of heat exchanger per unit 1
Fan
Fan type Direct drive propeller fan
Fans per unit 1
Outer diameter mm 544
Revolutions rpm 822
Nominalairow m
3
/min 80
Motor
Shell Drip-proof type enclosure
Starting Direct current control
Power W 200
Quantity 1
Insulation class E
Compressor
Model GTH356SDPC9FQ
Oil type ACS68R
Quantity 1.65
