3 General data
Component data
TCGB0136 rev.1 - 05/2021
43
3
3.4 Component data
RAS-(3-6)H(V)(R/N)C2(E)
MODEL RAS-3HVRC2 RAS-4H(V)(R/N)C2E RAS-5H(V)(R/N)C2E RAS-6H(V)(R/N)C2E
Heat
exchanger
Type Multi-passcross-nnedtube
Pipe material Copper
Outer diameter mm 7 7
Rows 2
Number of tubes in the heat
exchanger
44 108
Fin material Aluminium
Fin pitch 1.45 1.4
Maximum operating
pressure
MPa 4.15
Total front area m
2
0.47 1.11
Number of heat exchanger per unit 1
Fan
Fan type Direct drive propeller fan
Fans per unit 1
Outer diameter mm 449 544
Revolutions rpm 970 822
Nominalairow m
3
/min 45 80
Motor
Shell Drip-proof type enclosure
Starting Direct current control
Power W 50 200
Quantity 1 1
Insulation class E
Compressor
Model GTD163UKQA8LTH GTH356SDPC9FQ
Oil type ACS68R ACS68R
Quantity 0.75 1.65
