4 Capacities and selection data
Maximum cooling capacity
TCGB0136 rev.1 - 05/2021
54

R410A single phase
All temperatures in ºC.
Outdoor unit
Outdoor air inlet
temperature (DB)
Indoor air inlet temperature WB (ºC) / (DB (ºC))
15/(21) 19/(27) 23/(32)
CAP
max
IPT EER
CAP
max
IPT EER
CAP
max
IPT EER
RAS-4HVN(C/P)2E
25 10.6 3.42 3.10 11.8 3.49 3.38 13.1 3.57 3.38
30 10.3 3.51 2.94 11.5 3.59 3.20 12.8 3.68 3.20
35 10.0 3.69 2.71 11.2 3.79 2.95 12.4 3.87 3.02
40 9.7 3.93 2.47 10.9 4.05 2.69 11.9 4.07 2.69
RAS-5HVN(C/P)2E
25 13.2 4.39 3.01 14.7 4.48 3.28 15.8 4.44 3.56
30 12.7 4.46 2.85 14.3 4.60 3.11 15.4 4.56 3.37
35 12.1 4.60 2.63 14.0 4.88 2.87 14.8 4.75 3.12
40 11.5 4.79 2.40 13.0 4.96 2.62 14.0 4.92 2.85
RAS-6HVN(C/P)2E
25 14.0 4.53 3.08 15.3 4.56 3.36 18.1 4.96 3.65
30 13.6 4.66 2.92 14.9 4.69 3.18 15.9 4.61 3.46
35 12.5 4.65 2.69 14.0 4.91 2.85 15.2 4.77 3.19
40 11.9 4.83 2.46 13.3 4.95 2.68 14.6 5.00 2.91
? NOTE
IPTdataconsideringOutdoorUnitonly.

R410A three phase
All temperatures in ºC.
Outdoor unit
Outdoor air inlet
temperature (DB)
Indoor air inlet temperature WB (ºC) / (DB (ºC))
15/(21) 19/(27) 23/(32)
CAP
max
IPT EER
CAP
max
IPT EER
CAP
max
IPT EER
RAS-4HN(C/P)2E
25 10.6 3.42 3.10 11.8 3.49 3.38 13.1 3.57 3.38
30 10.3 3.51 2.94 11.5 3.59 3.20 12.8 3.68 3.20
35 10.0 3.69 2.71 11.2 3.79 2.95 12.4 3.87 3.02
40 9.7 3.93 2.47 10.9 4.05 2.69 11.9 4.07 2.69
RAS-5HN(C/P)2E
25 13.2 4.39 3.01 14.7 4.48 3.28 15.8 4.44 3.56
30 12.7 4.46 2.85 14.3 4.60 3.11 15.4 4.56 3.37
35 12.1 4.60 2.63 14.0 4.88 2.87 14.8 4.75 3.12
40 11.5 4.79 2.40 13.0 4.96 2.62 14.0 4.92 2.85
RAS-6HN(C/P)2E
25 15.5 6.11 2.54 17.0 6.15 2.77 18.1 6.03 3.00
30 15.1 6.28 2.40 16.6 6.33 2.62 17.7 6.22 2.85
35 14.3 6.42 2.22 16.0 6.61 2.42 16.9 6.43 2.63
40 13.5 6.66 2.03 15.1 6.83 2.21 16.2 6.75 2.40
? NOTE
IPTdataconsideringOutdoorUnitonly.
