4 Capacities and selection data
Maximum heating capacity
TCGB0136 rev.1 - 05/2021
56

R410A refrigerant single and three phase
All temperatures in ºC.
Outdoor
unit
Outdoor
air inlet
temperature
(DB)
Indoor air inlet temperature WB (ºC) / (DB (ºC))
15 16 18 20 22 24 26 28
CAP
max
IPT
CAP
max
IPT
CAP
max
IPT
CAP
max
IPT
CAP
max
IPT
CAP
max
IPT
CAP
max
IPT
CAP
max
IPT
RAS-4H(V)N(C/P)2E
-20 8.20 3.56 8.09 3.57 7.88 3.62 7.66 3.65 7.42 3.68 7.19 3.71 6.96 3.74 6.73 3.78
-15 9.39 3.68 9.29 3.71 9.09 3.77 8.89 3.83 8.68 3.88 8.46 3.94 8.24 4.00 8.02 4.06
-10 10.55 3.83 10.47 3.87 10.31 3.96 10.14 4.04 9.94 4.12 9.73 4.19 9.52 4.27 9.31 4.35
-5 11.74 3.85 11.67 3.90 11.53 4.00 11.38 4.10 11.19 4.19 11.00 4.28 10.81 4.38 10.62 4.49
0 12.92 3.63 12.86 3.69 12.74 3.79 12.62 3.90 12.45 4.00 12.26 4.10 12.07 4.21 11.88 4.32
5 14.01 3.52 13.97 3.58 13.89 3.69 13.77 3.80 13.62 3.91 13.45 4.02 13.28 4.13 13.11 4.26
10 15.48 3.98 15.47 4.05 15.45 4.20 15.35 4.33 15.23 4.47 15.07 4.59 14.91 4.73 14.75 4.88
15 17.12 4.76 17.10 4.84 17.07 5.01 17.05 5.20 16.94 5.36 16.78 5.52 16.62 5.69 16.46 5.88
RAS-5H(V)N(C/P)2E
-20 8.62 4.01 8.58 4.07 8.51 4.19 8.44 4.31 8.40 4.46 8.37 4.62 8.34 4.79 8.31 4.97
-15 10.26 4.32 10.22 4.38 10.15 4.52 10.12 4.67 10.03 4.81 10.00 4.99 9.97 5.18 9.94 5.38
-10 11.95 4.66 11.92 4.74 11.87 4.90 11.79 5.05 11.74 5.22 11.72 5.42 11.70 5.63 11.68 5.86
-5 13.65 4.81 13.61 4.89 13.53 5.04 13.46 5.21 13.37 5.37 13.31 5.56 13.25 5.76 13.19 5.98
0 15.84 4.79 15.79 4.87 15.69 5.02 15.60 5.18 15.49 5.34 15.40 5.52 15.31 5.71 15.22 5.91
5 18.04 4.89 18.00 4.97 17.92 5.13 17.81 5.30 17.67 5.46 17.54 5.64 17.41 5.83 17.28 6.03
10 19.04 5.26 19.00 5.35 18.92 5.52 18.79 5.69 18.65 5.87 18.47 6.04 18.29 6.22 18.11 6.42
15 19.74 5.88 19.69 5.98 19.60 6.17 19.49 6.37 19.35 6.57 19.13 6.75 18.91 6.95 18.69 7.16
RAS-6H(V)N(C/P)2E
-20 9.30 4.03 9.25 4.09 9.15 4.20 9.10 4.33 9.03 4.47 9.00 4.63 8.97 4.81 8.94 5.00
-15 11.04 4.33 11.01 4.40 10.96 4.54 10.89 4.68 10.85 4.85 10.82 5.02 10.79 5.22 10.76 5.42
-10 12.80 4.65 12.76 4.72 12.96 4.97 12.64 5.03 12.59 5.21 12.55 5.39 12.51 5.59 12.47 5.81
-5 14.87 4.88 14.82 4.96 14.73 5.11 14.64 5.28 14.55 5.45 14.48 5.64 14.41 5.85 14.34 6.07
0 17.46 4.91 17.41 4.99 17.31 5.15 17.20 5.31 17.08 5.48 16.97 5.66 16.86 5.85 16.75 6.06
5 20.11 5.07 20.04 5.14 19.90 5.30 19.75 5.46 19.61 5.63 19.45 5.81 19.29 6.00 19.13 6.20
10 21.15 5.44 21.10 5.53 21.00 5.71 20.89 5.90 20.80 6.10 20.66 6.30 20.52 6.52 20.38 6.75
15 22.31 6.18 22.22 6.27 22.04 6.45 21.90 6.65 21.76 6.87 21.64 7.10 21.52 7.35 21.40 7.61
? NOTE
IPTdataconsideringOutdoorUnitonly.
