Chapter 2: System controller
The storage systems are equipped with dual controllers for communicating with a data
host.
Each controller includes the following internal components such as a processor, dual in-
line cache memory modules (DIMMs), cache ash memory (CFM), battery, and fans. The
controller has an Ethernet connection for out-of-band management using Hitachi Device
Manager - Storage Navigator. If the data path through one controller fails, all drives
remain available to data hosts using a redundant data path through the other controller.
The controller is equipped with LED indicators for monitoring its operating conditions
and notifying possible component replacement.
CBL controller chassis
The controller chassis houses controllers, backup fan modules, and power supplies. The
chassis also includes specic functional LEDs located on the front and rear of controller
to provide its operating status.
The following table lists the controller board specications.
Component VSP F700
Chassis (4U) DW850-CBL
Controller board DW-F850-CTLM
Number of DIMM slot 8
Cache memory capacity 64 GiB to 256 GiB
Data encryption N/A
CBL controller front panel bezel LEDs
The following table describes the denitions of the CBL controller front panel bezel LEDs.
Chapter 2: System controller
Hitachi Virtual Storage Platform F700 Hardware Reference Guide 14
