Appendix F: Non-Hitachi racks
All storage systems can be installed into non-Hitachi racks.
The following describes the requirements and guidelines for installing the storage
system into a non-Hitachi rack.
Non-Hitachi rack support
The storage system supports non-Hitachi racks that meet Hitachi specications.
Observe the following mounting guidelines for non-Hitachi racks:
■
The VSP Gx00 models support any 4-post, EIA-310-D compliant rack that has
adequate airow and weight capacity.
■
PDUs must be mounted properly to avoid any issues while servicing the storage
system. The PDU receptacles must face toward the back (not toward each other). The
area behind the storage system and between the vertical 19-inch mounting posts
must be free of PDUs and cable loops.
Hitachi Universal V2 Rack rail kits
Use rail kits to mount the Hitachi Virtual Storage Platform family storage system in a
Hitachi Universal V2 Rack.
The following tables list the rail kit information for the specied storage systems.
Table 33 Rail kits for VSP Gx00 models
Rail kit Hitachi Universal V2 Rack Third-party rack
Controller UNI
1
UNI
1
DBS, DBL, and DBF drive
trays
CGR
2
UNI
1
DB60 dense intermix drive
tray
Use the rail kit supplied with the DB60 dense intermix
drive tray.
SVP server Use the rail kit supplied with the SVP server.
Notes:
1. UNI: Universal rail kit A34V-600-850-UNI.
Appendix F: Non-Hitachi racks
Hitachi Virtual Storage Platform G350, G370 Hardware Reference Guide 126
