Getting Started
19
Eyepiece Adjustment
To use the electronic viewfinder, pull out the eye cup all the way when using it and
adjust the diopter control so that the subject is seen most clearly in the viewfinder.
Always push in the eye cup after use.
Attaching the Optional Wide or Tele Converter Lens
1. To remove the lens hood, turn it counterclockwise.
2. Remove both caps of the converter lens.
3. Screw the lens into the threads on the camera/recorder lens assembly.
To Next Page
