Hitachi WL200 Series

Chapter 8 PROFINET Specification
36
Bit
Value
Significance
Description
0
Coast Stop Activated
(OFF 2)
When STW1 bit1 is OFF, this bit is OFF.
5
1
Quick Stop Not Activated
When STW2 bit1 is ON, this bit is ON.
0
Quick Stop Activated
(OFF 3)
When STW2 bit1 is OFF, this bit is OFF.
6
1
Switching On Inhibited
When the state is “Switching On Inhibited”, this bit
is ON.
0
Switching On Not Inhibit
When the state isn’t “Switching On Inhibited”,
this bit is OFF.
7
1
Warning Present
When warning occurs in inverter or WJ-PN, this bit is
ON.
0
No Warning
No warning occurs in inverter or WJ-PN.
8
1
Speed Error Within
Tolerance Range
When the output frequency reaches the set
frequency, this bit is ON.
0
Speed Error Out Of
Tolerance Range
When the output frequency doesn’t reach the set
frequency, this bit is OFF.
9
1
Control Requested
WJ-PN can accept data that is communicated by
PROFINET.
0
No Control Requested
WJ-PN can’t accept data that is communicated by
PROFINET.
10
1
f Or n Reached Or
Exceeded
When the output frequency reaches or exceeds the
set frequency, this bit is ON.
This bit is same as FA2 of WJ200 / WL200. You need
to set C042 and C043.
0
f Or n Not Reached
When the output frequency doesn’t reach and
exceed the set frequency, this bit is OFF.
This bit is same as FA2 of WJ200 / WL200. You need
to set C042 and C043.
11
-
15
Reserved
