8.2.3 Icons for the room thermostat view
Icon Name Values Explanation
Manual/Auto mode
Manual mode
Auto mode with timer setting
Auto mode without timer setting
Setting/Room
temperature
Setting temperature
Room temperature
End of timer period The end hour of the timer period is indicated below this icon
End of holiday period The end hour of the holiday period is indicated below this icon
Setting temperature
This icon appears while the setting temperature is being changed, and indicates the actual
temperature
Next screen
When room thermostat has been congured for both circuit 1 and 2, this icon appears at the right
side of the screen to indicated that there is a 2nd room thermostat view
