Hitachi YUTAKI RWM-2R1E Instruction And Operation Manual

CODE Description Default Value Range Steps Units
Application
Notes
S SC S80 M
Space Heating
If LCDM (Controller type (LCDM)) is
selected "Room" or "Unit+Room"
SWP Swimming Pool Disabled
Disabled /
Enabled
- - ○ ○ ○ ○
HES Heating source HP Only
H P O n ly
HP + Heater
HP + Boiler
HP + Heat. +
Boil.
- - ○ ○ ○ ○
“HP+Heat+Boil” is not available for
YUTAKI S80
SOLStSet
Solar
Combination
Disabled
Disabled
Input demand
Total control
- - ○ ○ ○ ○
If Status (DHWs) is “Disabled” this
parameter is forced to “Disabled” and
it is not displayed
8.5.2.3 Screen 3
This screen is displayed only when the unit is enabled to operate in heating and cooling modes.
CODE Description Default Value Range Steps Units
Application
Notes
S SC S80 M
Space Cooling
If LCDM(Controller type (LCDM)) is
selected “Room” or “Unit+Room”
C1WC Circuit 1 Fix
Disabled
Points
Fix
- - ○ ○ - ○
C2WC Circuit 2 Disabled
Disabled
Points
Gradient
Fix
- - ○ ○ - ○
8.5.2.4 Screen 4
CODE Description Default Value Range Steps Units
Application
Notes
S SC S80 M
External Elements
If Controller type (LCDM) is selected
as “Unit” or “Unit + Room”
COT Central Mode Not installed
Local/ Air /
Water/ Full
- - ○ ○ ○ ○
RTType
Thermostats
Type
-
None
Wired
Wireless
- - ○ ○ ○ ○
Visible only if Controller type
(LCDM)= “Unit”.
Wireless available only when
LCDM(Controller type (LCDM))=
“Unit”. If LCDM(Controller type
(LCDM))= “Unit+Room”, RTType is
forced to “Wired”
-
Check RT
Address
- - - - ○ ○ ○ ○ Only available if RTType= “Wired”
DetectedRTh
Detected
Circuits
- - - - ○ ○ ○ ○ Only available if RTType= “Wired”
Thermostat
1 (otC1)
Thermostat 1 -
None
C1
C2
C1+C2
- - ○ ○ ○ ○
Only available if LCDM(Controller
type (LCDM))= “Unit” and RTType=
“Wireless”
Thermostat
2 (otC2)
Thermostat 2 -
None
C1
C2
C1+C2
- - ○ ○ ○ ○
Only available if LCDM(Controller
type (LCDM))= “Unit” and RTType=
“Wireless”
? NOTE
Wizard can be re-launched by doing a factory reset (available only for Installer mode.
UNIT CONTROLLER
PMML0335A rev.1 - 04/2016
130
