3.4.2.4 DHW tank
Model DHWS200S-2.7H2E DHWS260S-2.7H2E
Power supply - 1~230V 50Hz
Casing
Material - Precoated galvanised steel
Color - Pure white (RAL 9010)
Dimensions
Unit
Height
Separated tank
mm
1282(*3) 1591(*3)
Integrated tank 1980(*3) 2289(*3)
Width mm 600
Depth (with connections) mm 648 (675)
Packing
Height mm 1444 1753
Width mm 644
Depth mm 722
Volume m
3
0.67 0.82
Weight
Net kg 72 87
Gros kg 82 98
Packing Material Carton - Wood - Plastic - Polypropylene bands
Tank
Net water volume L 190 250
Material AISI 444
Maximum tank working temperature ºC 75
Max tank water working pressure bar 10
Max heating coil water working temperature bar 75
Max heating coil water working pressure bar 3
Tank insulation
Material NEOPOR
Thickness mm 50
Heat exchanger
Quantity 1
Coil surface area m
2
1.6
Tank’s heater
Quantity 1
Heater rating kW 2.7
Type Immersion heater type
Piping connections
Heating coil inlet connection in. Flexible pipe (G 1” male)
Heating coil outlet connection in. Flexible pipe (G 1” male)
DHW inlet connection in. Flexible pipe (G 3/4” male)
DHW outlet connection in. Flexible pipe (G 3/4” male)
Mechanical thermostat (adjustable and security) Yes (adjustable 35~85ºC; cut-out: 90ºC)
Protection Anode protection
Wired remote controller PC-ARFHE
GENERAL DATA
PMML0335A rev.1 - 04/2016
58
