Hitachi YUTAKI RWM-2R1E Instruction And Operation Manual

Model
RWD-4.0NWE-
(200/260)S
RWD-5.0NWE-
(200/260)S
RWD-6.0NWE-
(200/260)S
Power supply - 1~ 230V 50Hz / 3N~ 400V 50Hz
Noise level (sound power) dB(A) 39 39 39
Cabinet
Material - Precoated galvanised steel
Colour - Pure white (RAL 9010)
Unit dimensions
Height (with connections) mm 1750 (1816) (*3)
Width mm 600
Depth mm 733
Packaging dimensions
Height mm 1950
Width mm 651
Depth mm 770
Packaging volume m³ 0.98
Packaging materials - Wood - Carton - Plastic
Net weight
Tank model: 200 L
kg
124 126
Tank model: 260 L 139 141
Gross weight
Tank model: 200 L
kg
135 137
Tank model: 260 L 150 152
Refrigerant pipes
connection
Connection type - Flare nut connection
Liquid pipe diameter mm (in.) Ø9.52 (3/8”)
Gas pipe diameter mm (in.) Ø15.88 (5/8”)
Space heating pipes
connection
Connection type - Screwed connection
Shut-off valves mm (in.) G 1-1/4” (male) - G 1-1/4” (male)
Inlet pipe diameter mm (in.) G 1-1/4” (female)
Outlet pipe diameter mm (in.) G 1-1/4” (female)
DHW pipes connection
Connection type - Screwed connection
Inlet pipe diameter mm (in.) G 3/4” (female)
Outlet pipe diameter mm (in.) G 3/4” (female)
Working range
(Heating)
Outdoor ambient temperature ºC (DB) -25~25
Outlet water temperature ºC 20~60
Working range
(Cooling)
Outdoor ambient temperature ºC (DB) 10~46
Outlet water temperature ºC 5~22
Working range (DHW)
Outdoor ambient temperature ºC (DB) -25~35
Tank water temperature ºC 30~75
GENERAL DATA
PMML0335A rev.1 - 04/2016
40
