OPERATING THE MACHINE
5-27
ATTACHMENT CONNECTION PARTS
The attachment hydraulic line and connection parts are lo-
cated as illustrated below. When the attachment is dis-
connected, be sure to install caps or plugs to the ends of
both the arm and attachment side hydraulic lines to pre-
vent dust from entering or from sticking.
M1CE-05-001
When the attachment is disconnected:
Part No. List (Fill attachment manufacturer’s part Nos. in the blank spaces.)
Maker Adapter Size Adapter
Cap
Plug Hose
Form / Size
Male-Type
PF-UNF
PF1-1-1/16-12UN 4456399 4222711 4222264
PF3/4-3/4-/16UN
※
4279302 4223519 4225492
Form / Size
Female-Type
PF-PF30
q
PF1-PF3/4 4129457 9718916 4222047
PF3/4- PF 1/2
※
4129227 9719234 4095927
Form / Size
Male-Type
PF-PF30
q
PF1-PF3/4 4456120 4222715 4222044
PF3/4-PF1/2 4222714 4222043
※
When using the adapter shown with mark
※
, reducer
(P/N 4263448) must be installed.
Ada
ter
Ca
Plu
Hose
Plug Thread Size: JIS B2351 O-Type PF1
Tightening Torque: 205 N·m (21 kgf·m)
Ada
ter
Ca
Reducer
To Next Page
