OPERATING THE MACHINE
5-28
OBJECT HANDLING --- IF EQUIPPED
CAUTION: When you use machine for object
handling, be sure to comply with all local regula-
tions.
Cables, straps, or ropes can break, causing seri-
ous injury. Do not use damaged chains, frayed
cables, slings, straps, or ropes to crane.
Never move the load quickly. Never move load
over a person’s head. Do not allow any persons
near load.
Keep all persons away from wire-rope-attached
load, lifted or sitting on the ground unless it is
securely sitting on blocks or on the ground.
Position upperstructure so that the travel motors
are at the rear.
Do not attach sling/chain to the bucket teeth.
Be sure that the maximum lifting load does not
exceed the rated load as shown in the lifting load
table plate or operator’s manual.
The overload alarm device warns the operator
with a buzzer sound when the lifting load ex-
ceeds the lifting capacity. If the buzzer sounds,
immediately move the load into the safety range,
or lower the load on the ground.
Be sure to turn the overload alarm device switch
ON while the machine is used for object handling.
When the machine specifications are modified
from the original specifications of the machine
delivered, for example, changing the front at-
tachment or track shoes, changing or new in-
stalling the overload alarm device may be require.
Be sure to consult your authorized Hitachi dealer.
Check that the specifications of the front and
machine to be used meet the specifications
shown on the rated lifting load table. If any dis-
crepancies between them are found, replace the
rated lifting load table so that no discrepancy is
found.
SA-014
M1CC-05-014
M1CC-01-015
M1G6-01-022
Rated lifting load table
To Next Page
